RV-3032-C7

	Type	Package [mm]	Interface	Features	Current @ 3V	Time Accuracy @ 25°C	Temp Comp -40/85°C	VDD min	VDD max	Temp. max	Documents	Temp. read back	Clock Out	Battery Switch	Battery Charge	Charge Pump	Time Stamp	Alarm	Timer	Unix Time	Offset Comp	RAM [bytes]	EEPROM [bytes]
	RV-3032-C7	3.2 x 1.5 x 0.8	I²C		160 nA		±2.5 ppm	1.3 V	5.5 V	+105°C	Datasheet App. Manual Free Samples	✓	✓	✓	✓	✓	✓	✓	✓		✓	16	32

RV-3032-C7 is a High Performance Temperature Compensated Real-Time Clock Module with I²C interface which offers the world's best time accuracy across industrial temperature range at ultra-low current consumption.

Factory calibrated temperature compensation of embedded 32.768 kHz crystal resonator provides ± 2.5 ppm accuracy from -40° to 85°C (±1.5 ppm 0° to 50°C; equivalent to ±0.13 sec/day and ±20 ppm +85° to +105°C). It allows extended battery life through timekeeping current as low as 160 nA.

Beside standard Real-Time Clock (RTC) functions like Calendar (100th of second through (leap-) year), Timer & Alarm, it includes an accurate high-resolution Temperature Sensor with programmable temperature window detection interrupt, smart power management functions and User EEPROM & RAM. External event detection interrupt with time stamp combined with programmable password, offers security solutions against fraud and hacking.

Ultra-small footprint and compact size with reliable vacuum-sealed metal lid provides all advantages of SMT fully integrated and easily implementable device for miniature and cost sensitive high volume applications.

Features

Performances

Factory Calibrated Temperature Compensation:
- -40 to +105 °C
High Time-Accuracy:
- ±1.5 ppm (0 to +50°C)
- ± 2.5 ppm (-40 to +85°C)
- ±20 ppm (+85 to +105°C)
Ultra-Low Power Consumption:
- 160 nA @ 3 V & 25 °C
Wide Timekeeping Voltage Range:
- 1.3 V to 5.5 V

Power Management

Automatic Backup Switchover with Interrupt Function
Trickle Charger with versatile Charge Pump allowing:
- VBACK ≥ VDD
- Use of 1.75 V TDK CeraCharge™
Supply Voltage Drop Detection (1.3 V) with Interrupt

Tamper Detection / Fraud Protection

Timestamped External Event Input Detection with Interrupt
Programmable Password Protection against Hacking
Configuration EEPROM

Temperature Monitoring

12-bit Temperature Sensor:
- Accuracy: ± 1°C typ.
- Resolution: (0.0625°C/step)
Timestamped & Programmable Temperature Window Detection with Interrupt

Standard Interrupt

Internal Power-On Reset
Periodic Countdown Timer
Periodic Time Update (seconds, minutes)
Alarm for date, hour and minute

Time & Frequency Functions

100th seconds, seconds, minutes, hours, date, month, year and weekday
Automatic leap year correction
Programmable EEPROM Ageing Compensation
Programmable Clock Output for peripheral devices:
- Crystal Mode:
  - 32.768 kHz, 1024 Hz, 64 Hz, 1 Hz
- High-Frequency Clock mode:
  - 8192 Hz → 52 MHz with 8192 Hz steps and guaranteed output signal integrity

Memory Size
