CM9V-T1A 0.3
Type | Package |
Dimension
[mm] |
Frequency |
Load Cap. CL
[pF] |
Series Resistance
[typ / max kΩ] |
Documents | ||
---|---|---|---|---|---|---|---|---|
CM9V-T1A 0.3 | 1.6 x 1.0 x 0.35 | 32.768 kHz | 4.0 / 6.0 / 7.0 / 9.0 / 12.5 pF | -- / 90 kΩ |
데이터시트 애플리케이션 설명서 |
CM9V-T1A 0.3 is a low frequency SMT Quartz Crystal Unit that incorporates a tuning fork Quartz Crystal Resonator. It operates under vacuum in a hermetically sealed ceramic package with metal lid.
Features
- Ultra low profile (maximum height 0.35 mm)
- Outstanding hermetic sealing with gold-tin preform
- High stability and low aging guaranteed by hermetic sealing
- Available for extended operating temperature range
- Lightweight (2.2 mg)
- High shock and vibration resistant
- 100% Pb-free, RoHS-compliant
Ordering Information
Applications
- Smart Cards
- Ultra Thin Devices
- Wearables
- Portables
- IoT
- Industrial
- Health Care
