CM9V-T1A

Type Package Dimension
[mm] 		Frequency Load Cap. CL
[pF] 		Series Resistance
[typ / max kΩ] 		Documents pdf-ico
CM9V-T1A 1.6 x 1.0 x 0.50 32.768 kHz 4.0 / 6.0 / 7.0 / 9.0 / 12.5 pF 60 / 75 kΩ 数据表
应用手册

CM9V-T1A is a low frequency SMT Quartz Crystal Unit that incorporates a tuning fork Quartz Crystal Resonator. It operates under vacuum in a hermetically sealed ceramic package with metal lid.

Features

  • Ultra small size: 1.6 × 1.0 × 0.50 mm
  • Outstanding hermetic sealing with gold-tin preform
  • High stability and low aging guaranteed by hermetic sealing
  • Available for extended operating temperature range
  • Lightweight:  2.4 mg
  • High shock and vibration resistant
  • 100% Pb-free, RoHS-compliant
  • Automotive qualification according to AEC-Q200 available

Ordering Information

Applications

  • IoT
  • Wearables, Portables
  • Health Care
  • Metering
  • Industrial
  • Automotive
  • Ultra Small Devices

Dimensions
