CC4V-T1A

Type Package Dimension
[mm] 		Frequency Load Cap. CL
[pF] 		Series Resistance
[typ / max kΩ] 		Documents pdf-ico
CC4V-T1A 5.0 x 1.9 x 0.90 30 kHz to 200 kHz
201 kHz to 560 kHz
561 kHz to 1 MHz 		6.0 / 7.0 / 9.0 / 10.0 / 12.5 pF
9.0 pF
7.0 / 10.0 pF 		50 / 65 kΩ
3.2 / 5.0 kΩ
0.5 / 1.0 kΩ 		数据表
应用手册

CC4V-T1A is a low frequency SMT Quartz Crystal Unit that incorporates a tuning fork Quartz Crystal Resonator. It operates under vacuum in a hermetically sealed ceramic package with ceramic lid.

Features

  • Ultra small size: 5.0 × 1.9 × 0.9 mm
  • Outstanding hermetic sealing with gold-tin preform
  • High stability and low aging guaranteed by hermetic sealing
  • Available for extended operating temperature range
  • Lightweight:  26.5 mg
  • High shock and vibration resistant
  • 100% Pb-free, RoHS-compliant.

Ordering Information

Applications

  • IoT
  • Wearables, Portables
  • Health Care
  • Metering
  • Industrial
  • Ultra Small Devices

Dimensions
