CC8V-T1A Medical
Type | Package | Dimension [mm] | Frequency | Load Cap. CL [pF] | Series Resistance [typ / max kΩ] | Documents![]() | ||
---|---|---|---|---|---|---|---|---|
CC8V-T1A Medical | ![]() | 2.0 x 1.2 x 0.67 |
32 kHz / 32.768 kHz 100 kHz / 102.4 kHz | 4.0 / 7.0 / 9.0 / 12.5 pF |
50 / 70 kΩ 9 / 20 kΩ | Datasheet Product Doc. |
The CC8V-T1A Medical is a low frequency SMT Quartz Crystal Unit built with a Tuning Fork Crystal Resonator. Manufactured in accordance with the highest quality production technologies, it operates under vaccum in a Helium impervious full ceramic package.
CC8V-T1A Medical is dedicated for specific use in Class III implantable medical devices and benefits from long-term reliability which is of utmost importance and a hallmark of Micro Crystal’s entire medical implantable grade portfolio.
Features
- Safe for Helium environment: Ceramic lid with gold-tin preform-seal for best long-term hermeticity and aging stability
- Proprietary manufacturing and testing processes
- Extended operating temperature range
- Customer specific testing/screening on request
- Components and manufacturing traceability records retained
- Small size, low profile, lightweight
Ordering Information

Applications
- Pacemakers
- Defibrillators
- Neurostimulators
- Cardiac Monitoring Devices
- Implantable Drug Delivery Pumps
- Infusion Pumps
- Cochlear Implants
- Smart Orthopedic Implants
Documentation
Dimensions
